DigitaL IC Trainer with Digital Voltmeter Manufacturer,Supplier and Exporter in India
 (1).png)
Product Code : SCL-EE-12330
The Digital IC Trainer with Digital Voltmeter is an electronics laboratory training apparatus used for teaching digital IC experiments and measuring circuit voltage during practical work. It is designed for school physics labs, college electronics laboratories, STEM classrooms, vocational training centres, and teachers who need integrated logic-circuit training with voltage observation.
Product Description
The Digital IC Trainer with Digital Voltmeter by School Equipments helps students build, test, and verify digital electronics circuits using practical laboratory connections. The integrated digital voltmeter supports voltage checking during experiments, helping learners connect circuit theory with measurable electrical values.
This trainer is suitable for lessons on logic gates, truth tables, flip-flops, counters, binary inputs, output indication, and digital circuit troubleshooting, subject to the confirmed supplied configuration. It fits within Electricity and Electromagnetism Equipment, Physics Lab Equipment, Lab Equipment, and STEM Lab Kits.
Key Features
- Digital IC experiment platform: Supports practical learning of logic ICs and digital circuit behaviour.
- Built-in digital voltmeter: Allows voltage measurement during circuit testing; measurement range [confirm].
- Logic gate learning: Suitable for AND, OR, NOT, NAND, NOR, XOR, and XNOR demonstrations, if supported by the supplied kit.
- Truth-table verification: Helps students compare input combinations with observed output states.
- Sequential circuit study: Can support flip-flop, counter, register, and clock-based experiments, subject to confirmed configuration.
- Clear input-output observation: Enables learners to apply logic levels, monitor voltage, and record results.
- Low-voltage educational use: Intended for supervised school, college, and vocational electronics practicals.
Technical Specifications
|
Specification |
Detail |
|
Product name |
Digital IC Trainer with Digital Voltmeter |
|
Brand |
School Equipments |
|
Product category |
Digital Electronics Trainer / Physics Electricity Teaching Apparatus / STEM Training Kit |
|
Primary keyword |
Digital IC Trainer with Digital Voltmeter |
|
Secondary keywords |
digital IC trainer, logic gate trainer, digital electronics trainer, IC trainer kit, digital voltmeter trainer, flip-flop trainer, counter circuit trainer, STEM electronics kit |
|
Intended users |
Schools, colleges, electronics labs, STEM labs, vocational training centres, and teacher demonstration rooms |
|
Dimensions / weight |
Not specified |
|
Standards or certifications |
Not specified; verify before publishing |
What's Included in the Kit
- 1 Digital IC Trainer with Digital Voltmeter main unit
- Built-in digital voltmeter
- Patch cords or connecting leads
- Digital ICs for experiments
- Experiment manual or instruction sheet
- Power cord or adaptor
Applications / Uses
- Teaching digital electronics fundamentals in school and college laboratories.
- Demonstrating logic gates and truth-table verification.
- Studying flip-flops, counters, registers, and sequential logic circuits.
- Measuring circuit voltage during digital electronics experiments.
- Training students in wiring, input switching, output observation, and troubleshooting.
- Supporting STEM lessons, vocational electronics programs, and project-based learning.
How to Use the Digital IC Trainer with Digital Voltmeter
- Place the trainer on a dry, stable laboratory bench.
- Check the confirmed supply rating and voltmeter range before powering the unit.
- Select the required experiment from the approved manual.
- Insert the IC only in the correct orientation, if removable ICs are used.
- Connect the circuit using patch cords according to the experiment diagram.
- Apply logic inputs using the available switches or input terminals.
- Use the digital voltmeter terminals or meter points to observe voltage values.
- Record the truth table, output state, and voltage readings for comparison with theory.
Safety note: Do not exceed the confirmed power-supply or digital voltmeter range. Switch off the trainer before inserting ICs, removing ICs, or changing circuit wiring.
Care & Maintenance
- Store the trainer in a dry, dust-free cabinet after use.
- Keep IC sockets, terminals, switches, meter points, and patch cords clean.
- Do not force ICs into sockets or connect wires to incorrect terminals.
- Inspect the power cable, adaptor, panel, and voltmeter display before each practical session.
Why Choose School Equipments
School Equipments supplies physics apparatus, electronics training kits, STEM lab kits, and educational laboratory equipment for schools and institutions. The brand supports practical science learning through products designed for classroom demonstration and student laboratory work. Its product range includes electricity and electromagnetism apparatus, electronics lab trainers, school science supplies, and STEM teaching aids. For a related electronics teaching product, see the Alpha Electronics Physics Students Kit.
Frequently Asked Questions
What is a Digital IC Trainer with Digital Voltmeter used for?
A Digital IC Trainer with Digital Voltmeter is used to teach digital electronics experiments and measure circuit voltage during practical work. It helps students test logic circuits and verify results.
Is this trainer suitable for school and college labs?
Yes, it is suitable for school physics labs, college electronics labs, STEM classrooms, and vocational training centres. The experiment list should be checked against the course syllabus.
Which experiments can be performed on this trainer?
Common experiments may include logic gates, truth tables, flip-flops, counters, registers, and combinational circuits. Confirm the supplied IC list and experiment manual before publishing.
What is the use of the digital voltmeter in this trainer?
The digital voltmeter is used to observe voltage values at selected circuit points. This helps students connect digital logic operation with measurable electrical signals.
Does the trainer include ICs and patch cords?
The supplied data does not confirm the accessory list. Verify whether ICs, patch cords, manual, and power cord are included with the final model.
What should be checked before switching on the trainer?
Check the power rating, IC orientation, wiring connections, input terminals, output terminals, voltmeter range, and patch cords before switching on the trainer.
For more digital electronics and circuit teaching products, browse Electricity and Electromagnetism Equipment from School Equipments.
