Quick Answer: The Regulated PSU supplies a regulated 0-32V dc at 2A, working as a constant voltage or constant current source with a 3 digit backlit display.
Last updated: October 2026
Key Features
Constant voltage, constant current operation
Output continuously adjustable through 0-32V, maximum 2A
Output voltage and current limit pre-set facility
Low output ripple
Electronic overload and short-circuit protection
4mm output sockets
Technical Specifications
Specification
Value
Output
0 - 32V dc, coarse and fine control
Maximum current
2A
Fuse (rear panel)
1A time delay
Ratings
230V ac 50Hz
Temperature limits
0 - 40°C
Dimensions
(W)95mm x (H)177mm x (D)285mm
About This Product
A useful point of this unit is that it can show the set voltage and current limit before any load is connected. The coarse control brings the output close to the required voltage, and the fine control trims it. Because the current limit is fixed in advance, components under test are protected from accidental damage. Export supply of the Regulated PSU can be arranged to laboratories and schools in Italy, Uruguay, Timor-Leste, Barbados and Laos.
