Loading Capacitor 1.2KVAR Bank Manufacturer,Supplier and Exporter in India

Product Code : SCL-EE-12428

The Loading Capacitor 1.2KVAR Bank is a capacitive load bank used for AC circuit experiments, reactive power demonstration, and power factor correction training in physics, electrical engineering, and TVET laboratories. It helps learners observe how capacitive loads affect current, phase angle, reactive power, and overall AC circuit performance.

Product Description

The Loading Capacitor 1.2KVAR Bank by School Equipments is designed for practical demonstrations where a controlled capacitive load is required. It is suitable for experiments involving leading current, capacitive reactance, reactive power, apparent power, and the comparison of resistive, inductive, and capacitive load behavior.

This product belongs to Electricity & Electromagnetism lab equipment and supports advanced electrical training in schools, colleges, engineering labs, and vocational institutes. Exact voltage rating, current rating, phase type, capacitance steps, discharge arrangement, enclosure material, terminals, and duty cycle should be confirmed from the final manufacturer datasheet before publishing.

Key Features

• 1.2 kVAR capacity: Provides a supplied reactive load capacity of 1.2 kVAR for AC laboratory demonstrations.
• Capacitive load behavior: Demonstrates leading current, capacitive reactance, and phase difference in AC circuits.
• Power factor correction training: Useful for showing how capacitors can improve lagging power factor in suitable circuits.
• Practical learning value: Helps students compare meter readings under capacitive and inductive loading.
• Compatible instrument use: Can be used with suitable voltmeters, ammeters, wattmeters, power factor meters, and energy meters after rating verification.
• Construction details: Capacitor type, enclosure, terminals, discharge resistor, switching method, and insulation details are [confirm].
• Safety-led operation: Intended for supervised use with rated wiring, insulation, ventilation, discharge checks, and circuit protection.

Technical Specifications

What's Included in the Kit

• Loading Capacitor 1.2KVAR Bank main unit
• Input and output terminals
• Capacitor step switches or selector arrangement
• Discharge resistor or safety discharge system
• Operating manual or datasheet

Applications / Uses

• Demonstrating capacitive load behavior in AC circuits
• Studying reactive power, apparent power, and leading power factor
• Supporting power factor correction experiments in electrical labs
• Comparing capacitive and inductive load behavior in training circuits
• Using with compatible electrical meters and training panels after rating confirmation
• Supporting related experiments with the BEK Capacitor 1000F 25V, Decade Capacitance Box, Plug-In Electricity Cost Monitor, and Simple Circuit Module Lamp Holder

How to Use the Loading Capacitor 1.2KVAR Bank

1. Confirm the voltage, current, phase type, kVAR rating, capacitance steps, and duty cycle before use.
2. Place the capacitor bank on a dry, stable, and ventilated laboratory bench.
3. Connect the unit into the AC circuit according to the approved experiment diagram.
4. Connect compatible voltmeters, ammeters, wattmeters, and power factor meters as required.
5. Switch on the supply and apply the capacitive load only within confirmed safe limits.
6. Record voltage, current, wattage, power factor, and reactive power observations.
7. Switch off the supply and confirm safe discharge before changing connections or handling terminals.

Safety note: A 1.2 kVAR capacitor bank can retain stored electrical energy after disconnection. Use proper discharge procedures, rated cables, insulation, earthing where applicable, and qualified supervision.

Care & Maintenance

• Keep the capacitor bank clean, dry, and protected from dust and moisture.
• Inspect terminals, switches, wiring, enclosure, and insulation before every experiment.
• Confirm discharge before handling or storing the apparatus after use.
• Do not exceed the confirmed voltage, current, kVAR, phase, or duty-cycle rating.

Why Choose School Equipments

School Equipments manufactures and exports scientific laboratory instruments, lab experiment setups, science kits, mathematics kits, didactic models, and STEM training equipment. The Loading Capacitor 1.2KVAR Bank is positioned for institutions that need practical AC electrical load apparatus for power factor and reactive power training. The brand supports school, college, university, and vocational buyers with educational laboratory equipment. Final ratings and supplied accessories should always be checked against the official quotation or datasheet before procurement.

Frequently Asked Questions

What is a Loading Capacitor 1.2KVAR Bank used for?

A Loading Capacitor 1.2KVAR Bank is used to demonstrate capacitive AC load behavior, reactive power, leading current, and power factor correction in electrical laboratory circuits.

What does 1.2 kVAR mean in this product?

1.2 kVAR indicates the supplied reactive power capacity of the capacitive load bank. Voltage, current, phase type, and duty cycle must be confirmed separately.

Is this loading capacitor suitable for school laboratories?

Yes, it is suitable for supervised school, college, engineering, and TVET laboratories when operated within confirmed electrical ratings.

Can it be used for power factor correction experiments?

Yes, a capacitive load bank is useful for demonstrating how capacitors can improve lagging power factor in suitable AC circuits.

What instruments are used with a Loading Capacitor 1.2KVAR Bank?

Compatible voltmeters, ammeters, wattmeters, power factor meters, and energy meters may be used if their ratings match the circuit and load conditions.

Does a capacitor bank need discharging after use?

Yes. Capacitors can retain stored electrical energy after the supply is switched off, so discharge procedures must be followed before handling.

For related apparatus, explore more Electricity & Electromagnetism lab equipment from School Equipments.
